Aqua - MTP-MTP Type A (KeyUp KeyDown) MPO OM4 24 Core Fibre Trunk Cassette Cable
New
Express, Easy and Expandable MTP/MPO Fibre Solutions.
OM4 (OM3 Compatible) 24 Core Micro/Multi Fibre Trunk Cable - Type A Straight Method Polarity.
25 Year Performance Warranty.
Rapid 'Plug and Go' Fibre Network Deployment with no specialist tools required.
Trunk Cable to link directly to rear of LC Cassettes.
*Custom made to order, Allow 5-7 Days for delivery*
Are you looking to bulk purchase this product? If so, please see the below DISCOUNTED quantity breaks!
All quoted prices exclude VAT.
| Quantity | Discount | You Save |
|---|---|---|
| 100 | 20% | Up to £2,620.00 |
| 50 | 15% | Up to £982.50 |
| 25 | 10% | Up to £327.50 |
| 10 | 5% | Up to £65.50 |
Colour = Aqua with Black & Aqua Elite High Performance MTP Boots
Mode/Configuration = OM4 Type A (Key Up, Key Down) 24 Straight Channels, Pin 1-1 etc.
Connectors = End A=MTP, End B=MTP (or vice versa) Female
Availability = Made to order on a 5-7 day lead time
|
Express Delivery, Easy to Install (by IT department) and Expandable Flexible Multi 'Push On' (MPO) Fibre Solution. Multimode Fibre 50/125um, enhanced maximum insertion loss not exceeding 0.35dB but typically around 0.2dB over 50 Metres. Standard 500 mating cycles. Reliability and Uptime maximised. Latency, packet loss and cost minimised. |
|
 |
|
| Low Smoke Zero Halogen (LS0H/LSZH) cable sheath, subjected to tension, vibration and impact tests to ensure reliability. High precision guided pins, housed in Micro/Multi fibre cable, the size of a traditional patch lead - ideal for instant 10 Gigabit/10Gb/s rapid network deployment. Removes complexity of traditional fibre installations, with no specialist tools required so you can quickly maximise rack space with high density and high bandwidth links. | |
|
|
| Outside Cable Dimension 3mm/3.6mm, a fraction of the size of traditional terminated fibre providing a flexible but ruggedised product for optical performance. Reduced cable diameter means less cable tray, less airflow obstruction (reducing energy usage) and easy cabinet entry. Operating Temperature (-40C to +70C). Also available as an OM3 or Singlemode termination, Type B & C Polarity options, or external grade. Full solution design and measuring service with configurations for emerging 40Gbps and 100Gbps transmissions available using multiple fiber trunk cables. MTP/MPO is an ideal solution for Data Centre backbone infrastructure, Storage Area Networks (SAN's) using FCoE (Fibre Channel over Ethernet), large digital file transfer and direct links to Cisco 10GBase+ hardware. | |
|
|
| Pre-terminated in the UK (in-house) under controlled ISO9001 laboratory conditions using high quality components and enhanced US Conec. MTP connectors. These connectors are designed with a floating ferrule to ensure fiber contact integrity with an elliptical guide pin tip to minimise debris thus giving high precision guide pins. All MTP products are issued with a 25 years performance warranty for complete peace of mind. Each cable is 100% inferometer tested and individually bagged with the test certificate affixed to the outside of the bag. The cable can be labelled to your specific (alpha/numerical) numbering sequence and has a unique serial number applied. All cables meet and exceed IEC Standards 61754-7, TIA/EIA 604-5 Type MPO, ANSI HIPPI 6400. | |
|
|
| Other lengths and colours available - almost any cable can be made to order - please call 01442 890890 or email [email protected] for pricing. |
| Product Set | MTP Fibre Solution |
| Colour | Aqua |
| Sizing | 3.0mm |
| Jacket | LSZH |
| Type | 24 Core |
| Keyword Filter | Type A |
| Connector 1 | MTP |
| Connector 2 | MTP |
| Sub Category | OM4 |
